Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa

Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa
Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa
المعلومات الأساسية
مكان المنشأ: الصين
اسم العلامة التجارية: OPTFOCUS
إصدار الشهادات: 3C,CE,RoHS
رقم الموديل: OFS-PE-DT10
الحد الأدنى لكمية: 2 قطعة
الأسعار: USD 12.9 1piece
تفاصيل التغليف: الصندوق والكرتون
وقت التسليم: 6-14 يوم
شروط الدفع: L / C ، ويسترن يونيون ، T / T
القدرة على العرض: 10000 قطعة في الشهر
ﺎﺘﺼﻟ ﺍﻶﻧ
دور: POE ، دعم VLAN الموانئ: ين 8،24،16،10،2
حالة المنتجات: مخزون معدل الإرسال: 10/100 / 1000Mbps ، 10 / 100Mbps ، 10/100 / 1000M / 10G
قدرة التبديل: 8.8 جيجابت في الثانية ، 52 جيجابت في الثانية ، 16 جيجابت في الثانية ، 53 جيجابت في الثانية ، 1.25 تي وضع الاتصال: دوبلكس كامل ونصف دوبلكس
إصدار الشهادات: CE,CE RoHS FCC,FCC,RoHS,ISO9001 اسم المنتج: تبديل الألياف
ضمان: سنة واحدة منافذ PoE: 1-8 منفذ دعم PoE (15.4 واط)
معيار بو: IEEE802.3af /IEEE802.3 نوع الجهاز: تبديل اثرنت
طلب: نظام كاميرا cctv ، لاسلكي AP الصانع: شنتشن
درجة حرارة التشغيل: -40 ℃ ~ + 85 ℃ حالة: علامة تجارية أصلية 100٪

Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufacturers
Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa 0
Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa 1
Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa 2
Network Media 10BASE-T: Cat3,4,5 UTP(≤100 meter) 100BASE-TX: Cat5 or more UTP (≤100 meter)
Bandwidth 2Gbps (non-blocking)
Address Database Size 1K
Forwarding Mode Store-And-Forward
Network Protocols

IEEE 802.3i 10BASET; IEEE 802.3u 100BASETX; IEEE 802.3x Flow Control;

IEEE 802.1af DTE Power via MDI; IEEE 802.3af
LED Display System: power supply; Every Port: connecting, PoE working status
Power Supply Power input: AC100-240V 50/60Hz; (every country use a custom power plug)
PoE Ports Port 1-8 support POE
PoE Port Power 15.4W for each POE port
PoE Standard IEEE 802.3af
Led indicator

Green: Ethernet

Red:PoE

SW:

On: VLAN, 100meters

Flashing: VLAN, 250meters

Off: VLAN Closed,100meters

Flashing: VLAN Closed, 250meters
Working Environment

Operating Temperature: -20° ~ 55 ° C; Storage Temperature: -40 ° ~ 85 ° C;

Operating Humidity: 10% ~ 95%, non-condensing
Certification CE Mark ,commercial; CE/LVD EN60950, RoHS
Radiation CE mark, commercial; FCC Part 15 Class B; VCCI Class B; EN 55022 (CISPR 22), Class B
Transmission Distance Data transmission distance: 100m, 250m( when on 10M data rate with Cat6.)
Warranty 2year warranty



Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa 3
Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa 4
Packing & Delivery
Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa 5
Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa 6
Each product is packed in a high quality PE bag, Then put into a box or carton.
Company Profile
00:00

02:41

Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa 7
Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa 8
Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa 9
Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa 10
Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa 11
Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa 12
Our company:

Shenzhen OPTFOCUS Technology Co., Ltd was established in 2009, which is a High -tech manufacturer enterprise with 10 years' experience in global sales and services. Our company focus on professional R & D, production and sales of XPON access equipments, FTTH/FTTx solution and passive cabling system products. We also committed to provide Customized OEM & ODM services to Global communication distributors, Telecom Operators and System Integrator. OPTFOCUS manufacturing center covering area around 2,500 Square meter, and owning three production workshops, 9 production lines. Advantage of our company : 1 National High-tech enterprise certification; 2 Fiber Optical Innovative &production team Over 10 years; 3 Fiber optical active and passive components production Workshop; 4 Strict quality management system; 5 Professional One stop supply & service; 6 OEM&ODM available; 7 Reliable and Timely customer services;
FAQ
1. who are we?
We are based in Guangdong, China, start from 2009,sell to South America(30.00%),Southeast Asia(10.00%),Western Europe(10.00%),Central America(10.00%),Domestic Market(7.00%),South Asia(6.00%),North America(5.00%),Eastern Europe(5.00%),Mid East(5.00%),Northern Europe(5.00%),Africa(3.00%),Eastern Asia(3.00%),Southern Europe(00.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
G/EPON ONU,OLT,POE SWITCH,FIBER SWITCH,SFP

4. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,FCA；
Accepted Payment Currency:USD,EUR,CNY,CHF;
Accepted Payment Type: T/T,L/C,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Russian
Positive feedback from our customers:
Outdoor Waterproof Gigabit Ethernet PoE Switch 8 Port PoE Switch with Fiber For Video Surveillance Network Switch Manufa 13
